Laser cutting on three fiber and CO2 lasers.
Our three lasers, fiber and CO2, cut sheet steel, stainless and aluminum up to a quarter inch thick. Send us your DXF or STEP file and we nest the parts for material yield before the first sheet goes on the bed, which keeps your cost down and your lead time short. Because there is no tooling to make, a prototype and a production run cut from the same program.
- Machines
- 3
- Sources
- Fiber and CO2
- Sheet thickness
- To ¼ in
- Files
- DXF · DWG · STEP
Laser cutting in detail
Laser cutting is where most jobs start here. It handles the intricate outlines, tight hole patterns and one-off shapes that a punch cannot, and it does it without tooling, so a prototype and a production run cut from the same program.
Parts are nested across the sheet before cutting to hold material cost down, and the offcuts you see in the photographs are what is left after that. If a feature on your print will not cut cleanly at the gauge you have specified, we say so on the quote rather than after the run.
Specifications
Key specifications for laser cutting.
| Fiber laser | BesCutter 5 × 10Thin to mid-gauge sheet, fast on steel and aluminum |
|---|---|
| CO2 laser | Amada LASMAC LC 2415 αIV NTThicker plate and clean edges on stainless |
| Materials | CRS, HRS, galvanized, galvanneal, stainless, aluminum |
| Thickness | Cold rolled to 11 ga · hot rolled to ¼ in |
| Programming | Nested from your DXF or flat patternWe can unfold a STEP model if there is no flat |
Typical parts
- Flat blanks for the brake line
- Brackets, plates and gussets
- Perforated and slotted panels
- Display shelves, headers and sign plates
- Enclosure and chassis flats
Request a quote
Send the print for laser cutting. Upload a drawing, a flat pattern or a solid model with quantities, material and finish. The quote is priced against machine time on this floor, and we flag anything that will fight the tooling before you commit to a run.
